Frame
Lite Aluminium, endurance geometry, internal cable routing, 142x12mm axle, BB86, flat mount rear brakes, 1 1/2 headtube, max tyre 35c (32c with mudguards)
Fork
Carbon, 700x35C max wheel size
Headset
Acros ICR Merida external neck w/diecast splitring
Stem
Aluminium, 31.8mm diameter, -6 degree rise
Handlebar
Aluminium, 380mm (4XS-S), 400mm (M-L), 420mm (XL)
Grip
Merida ROAD Expert
Brake Type
Hydraulic disc
Brake Lever
Shimano CUES
Brake Calipers
Shimano CUES hydraulic disc
Tyres
Maxxis Detonator, 700x32C, fold
Wheel Size
700c
Rims
Merida Comp SL II, 23mm inner width, 24mm deep, aluminium, tubeless ready
Spokes
Black stainless
Front Hub
Joytech D981SB, 100x12mm, 28 spoke, Centerlock
Rear Hub
Joytech D872SB, 12-142mm, 28 spoke, Centerlock
Speeds
20
Front Derailleur
Shimano CUES
Rear Derailleur
Shimano CUES RD-U6000GS
Shift Levers
Shimano CUES disc
Chain
KMC xGlide
Cassette
Shimano LG300-10, 11-39 teeth, 10 speed
Chainset
Shimano CUES, 50-34 teeth, 165mm (4XS-XS), 170mm (S-M), 172.5mm (L-XL)
Bottom Bracket
Shimano SM-BB71-41B, Pressfit 86.5mm
Saddle
Merida Comp SL, 25% recycled material, V-mount
Seat Post
Merida Comp CC, 27.2mm diameter, in-line, aluminium
