Frame
CF3 carbon, Nano Matrix for impact resistance, internal cable routing, 142x12mm axle standard, BB86 BB standard, flat mount rear brake with Disc Cooler, 1 1/2 headtube, fully integrated seat clamp, max tyre size 700x35c (700x32c with mudguard)
Fork
Scultura Endurance CF3 Disc, carbon, 700x35C max wheel size
Headset
Merida Team SL (SE-301 neck)
Stem
Merida Expert SL 2PII, aluminium, -9 degree rise, incl. Merida SMART MOUNT
Handlebar
Merida Expert SL II, aluminium, (3XS-S) 380mm, (M-L) 400mm, XL 420mm
Grip
Merida ROAD Expert
Brake Type
Hydraulic Disc
Brake Lever
Shimano 105
Brake Calipers
Front: Shimano 105 Disc, Rear: Shimano 105 Disc
Tyres
Maxxis RE-FUSE, 700x32C, fold
Wheel Size
700c
Wheels
Rims: Merida Expert SL III, 23mm inner rim width, 26mm deep, aluminium, tubeless ready; Spokes: Double Butted Black stainless; Front Hub: Shimano TC500, 100x12mm, 28 spoke, Centerlock; Rear Hub: Shimano TC500-HL, 12x142mm, 28 spoke, Centerlock
Speeds
24
Front Derailleur
Shimano 105 Di2
Rear Derailleur
Shimano 105 Di2
Shift Levers
Shimano 105 disc Di2
Chain
Shimano M6100-12
Cassette
Shimano 105 R7101, 11-34 teeth, 12 speed
Chainset
Shimano 105 R7100, 50-34 teeth, crank length: (XXS-XS) 165mm, (S-M) 170mm, (L-XL) 172.5mm
Bottom Bracket
Shimano SM-BB71-41B, Pressfit 86.5mm
Saddle
Merida Expert SL II, V-mount, incl. Merida minitool
Seat Post
Merida Expert SL, 27.2mm diameter, in-line, carbon
