Rear hub | Alloy, e-bike specific, double sealed cartridge bearings, 12mm x 148mmBoost thru-axle, 32 hole |
Front hub | Alloy, double sealed cartridge bearings, 15mm x 110mm Boost thru-axle, 32 hole |
Spokes | DT Swiss New Champion 2.0mm, black stainless, brass nipples |
Rims | WTB HTZ i30 TCS 2.0 System, asymmetric, sleeved joint, super toughconstruction, tubeless ready, 32 hole |
Tyres | Maxxis Assigai WT, TR, 2.5in 120TPI, EXO+ casing, 3C Maxx Grip, DualCompound, Front; Maxxis Minion DHR II WT, TR, 2.4in 120TPI, DoubleDown, 3C Maxx Terra, Dual Compound, folding bead, rear |
Shift levers | SRAM GX AXS, two button, MMX, 12 speed |
Rear derailleur | |
Cassette | SRAM XS-1275 Eagle, 10-50T, 12 speed |
Chain | |
Crankset | Whyte, forged alloy, 155mm, direct mount 36T |
Seatpost | Crank Brothers HighLine 3, 30.9mm (M/L 150mm, XL 170mm travel),Highline ball socket remote lever |
Seat | Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail |
Bar | Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 780mm wide |
Stem | Whyte Enduro, 35mm bar bore, 35mm extension |
Grips | |
Front brakes | SRAM Code R, four piston with sintered metal pads, 220mm disc |
Rear brakes | SRAM Code R, four piston with sintered metal pads, 200mm disc |
Brake levers | |
eBike motor | Bosch Performance Line CX (Smart System) drive unit with 85Nmmaximum torque, 250W nominal power. Features four powersettings including Tour+, that allows riders to focus on ridingwhilst being economic on power usage, and eMTB mode whichautomatically adjusts |
eBike display | Bosch LED Remote allows for easy use and visibility for the rider,also connecting to Bosch’s eBike Flow App to give the rider evenmore insight and control at their fingertips |
eBike battery | Bosch PowerTube 750Wh internal, perfectly integrated into theframe with an intuitive lockable mechanism for easy removal.Reaches full charge in less than 6 hours, and just over 2 hours forhalf charge. Supplied with Bosch’s 4A Compact Charger |
eBike battery charger | |
Shock, stroke & sag | |
Eye to eye length | 230mm |
Weight | 26kg |
