Sizes available | M, L, XL |
Colour | Gloss black with matt black |
Frame | 6061 alloy, hydroformed T6 aluminium, multi-butted, custom drawn, tapered headtube, internal cable routing, Shape.it Link and 12mm x148mm Boost dropouts |
Fork | Fox Float 38, Performance Elite 29in, 160mm travel, 44mm offset with Grip2 damper, tapered steerer, 110mm x 15mm Boost, E-thru-axle |
Rear shock | Fox Float X Performance Elite DPS, EVOL LV, custom tuned for Whyte |
Headset | FSA No. 55/35 Orbit 1.5 ZS, 1.8in lower and 1 1/8in upper sealed cartridge bearings |
Rear hub | DT 350, 24T hardened steel ratchet, six bolt |
Front hub | DT 350 Boost six bolt |
Spokes | DT Hybrid straight pull |
Rims | DT HX 1700 alloy, hooked 30mm internal width |
Tyres | Maxxis Assigai WT, TR, 29in x 2.5in 120TPI, EXO+ casing, 3C Maxx Grip, Dual Compound, front; Maxxis Minion DHR II WT, TR, 29in x 2.4in 120TPI, Double Down, 3C Maxx Terra, Dual Compound, folding bead, rear |
Shift levers | SRAM AXS Pod, two button MMX, 12 speed |
Rear derailleur | SRAM GX T-Type AXS |
Cassette | SRAM XS-1275 Eagle, 10-52T, 12 speed |
Chain | SRAM GX T-Type Eagle, 12 speed |
Crankset | Race Face A-Effect, 165mm, ISIS with X-SYNC 2, Direct Mount 36T for Bosch Performance Line CX, black |
Seatpost | Crank Brothers HighLine 3, 30.9mm (M/L 150mm, XL 170mm travel), Highline ball socket remote lever |
Seat | Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail |
Bar | Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 800mm wide |
Stem | Whyte Enduro, 35mm bar bore, 35mm extension |
Grips | Whyte Lock-on Enduro |
Front brakes | SRAM Code RSC, four piston with sintered metal pads, 220mm disc |
Rear brakes | SRAM Code RSC, four piston with sintered metal pads, 200mm disc |
Brake levers | SRAM Code RSC, MMX |
eBike motor | Bosch Performance Line CX (Smart System) drive unit with 85Nm maximum torque, 250W nominal power. Features four power settings including Tour+, that allows riders to focus on riding whilst being economic on power usage, and eMTB mode which automatically adjusts |
eBike display | Bosch LED Remote allows for easy use and visibility for the rider, also connecting to Bosch’s eBike Flow App to give the rider even more insight and control at their fingertips |
eBike battery | Bosch PowerTube 750Wh internal, perfectly integrated into the frame with an intuitive lockable mechanism for easy removal. Reaches full charge in less than 6 hours, and just over 2 hours for half charge. Supplied with Bosch’s 4A Compact Charger |
eBike battery charger | Charger 4A (230V) |
Shock, stroke & sag | 57.5mm/16mm |
Eye to eye length | 230mm |
Weight | 26Kg |
