Sizes available | XS (27.5in), S (27.5in), M (29in), L (29in), XL (29in) |
Frame | 6061 alloy, hydroformed T6 aluminium, multi-butted, custom drawn, tapered headtube, internal cable routing, Shape.it Link and 12mm x148mm Boost dropouts |
Fork | RockShox ZEB 29in, 160mm travel, 44mm offset, DebonAir, Rush RC damper, Fast Black coating, tapered steerer, 110mm x 15mm Boost, Maxle Ultimate |
Rear shock | RockShox Deluxe Select R, Fast Black coating, adjustable rebound |
Headset | FSA No. 55R/35 Orbit 1.5 ZS, 1.8in lower and 1 1/8in upper sealed cartridge bearings |
Rear hub | Alloy, e-bike specific, double sealed cartridge bearings, 12mm x 148mm Boost thru-axle, 32 hole |
Front hub | Alloy, double sealed cartridge bearings, 15mm x 110mm Boost thru-axle, 31mm torque caps, 32 hole |
Spokes | DT Swiss New Champion 2.0mm, black stainless, brass nipples |
Rims | WTB HTZ i30 TCS 2.0 System, asymmetric, sleeved joint, super tough construction, tubeless ready, 32 hole |
Tyres | Maxxis Assigai WT, TR, 2.5in 120TPI, EXO+ casing, 3C Maxx Grip, Dual Compound, front; Maxxis Minion DHR II WT, TR, 2.4in 120TPI, Double Down, 3C Maxx Terra, Dual Compound, folding bead, rear |
Shift levers | SRAM GX AXS Eagle, two button, MMX, 12 speed |
Rear derailleur | SRAM GX AXS Eagle, 12 speed |
Cassette | SRAM PG1210, 11-50T, 12 speed |
Chain | |
Crankset | Whyte, forged alloy, 155mm, direct mount 36T |
Seatpost | Whyte drop.it Adjust, 30.9mm (M/L 140-170mm travel; XL 170-200mm travel), MMX Paddle remote lever |
Seat | Whyte Custom, dual density, triple panel design |
Bar | Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 780mm wide |
Stem | Whyte Enduro, 35mm bar bore, 35mm extension |
Grips | |
Front brakes | SRAM Guide RE, four piston with sintered metal pads, 220mm disc |
Rear brakes | SRAM Guide RE, four piston with sintered metal pads, 200mm disc |
Brake levers | |
eBike motor | Bosch Performance Line CX (Smart System) drive unit with 85Nm maximum torque, 250W nominal power. Features four powe r settings including Tour+, that allows riders to focus on riding whilst being economic on power usage, and eMTB mode which automatically adjusts |
eBike display | Bosch LED Remote allows for easy use and visibility for the rider,also connecting to Bosch’s eBike Flow App to give the rider even more insight and control at their fingertips |
eBike battery | Bosch PowerTube 750Wh internal, perfectly integrated into theframe with an intuitive lockable mechanism for easy removal. Reaches full charge in less than six hours, and just over two hours for half charge. Supplied with Bosch’s 4A Compact Charger |
eBike battery charger | |
Shock, stroke & sag | |
Eye to eye length | 230mm |
Weight | 26Kg |
