Set fire to the trails
Slack, low and ready to go has been the signature look of Whyte’s Trail Hardtails for their whole award-winning history but our latest frame has evolved to deliver maximum tyre space to 2.8in and even easier servicing. That way you never have to miss out on its blistering, blast everything ride, however muddy it is or how much you’ve been hammering the trails not the tools.
SPECIFICATION
Colour- Matt Burnt Orange Corn/Slate
Frame- 6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, SCR, Tapered Headtube, Internal Cable Routing with BBX63, Chainstay Post Mount Dropouts and 12mm X 148mm Boost Dropouts
Fork- RockShox Recon RL 29", 120mm Travel, 42mm Offset, Solo Air, Fast Black Coating, Adjustable Rebound, Tapered Alloy Steerer, 110mm x 15mm Boost, Maxle Lite
Rear Shock- N/A
Headset- FSA No. 57B Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Caged Bearings
Rear Hub- Alloy, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Thru Axle, 32 Hole
Front Hub- Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Thru Axle, 32 Hole
Spokes- DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples
Rims- WTB ST i27 TCS 2.0 System, Pinned Joint, Tubeless Ready, 32 Hole
Tyre- Maxxis Forekaster 29"x 2.35" Dual Compound, 60TPI
Shift Levers- SRAM SX Eagle
Front Mech- N/A
Rear Mech- SRAM SX Eagle, 12 Speed
Cassette- SRAM PG-1210 Eagle, 11-50, 12 Speed
Chain- SRAM SX Eagle, 12 Speed
Crankset- SRAM X1 Eagle, X-SYNC 2, Direct Mount 32T, DUB, 170mm, Boost 12 Speed
Bottom Bracket- SRAM DUB, BSA, 73mm
Seatpost- Whyte Drop.it, 30.9mm, S 125mm Travel, M/L/XL 150mm Travel, Paddle Remote Lever
Saddle- Whyte Custom
Handlebar- Whyte 6061 Alloy, 15mm Rise, 31.8mm, 780mm Wide
Stem- Whyte Alloy, 35mm Extension
Grips- Whyte Lock-on Enduro Grip
Brakes Front- Tektro HD-M535, 4 Piston, 2.3mm gauge 180mm Disc
Brakes Rear - Tektro HD-M535, 4 Piston, 2.3mm gauge 180mm Disc, Internal Routing
Brake Levers - Tektro M-535
Pedals- Fibre Reinforced Composite Platform
