| specification |
|---|
| colour | matt burnt orange corn/slate | cassette | sunrace csms8, ed black, 11-51, 11 speed |
| frame | 6061 alloy, hydro formed t6 aluminium, multi butted, scr, tapered headtube, get a grip seat clamp system, internal cable routing with bbx63 and chainstay post mount dropouts 12mm x 148mm boost | chain | kmc npbk 11 speed |
| fork | rockshox recon rl 27.5", 120mm travel, 37mm offset, solo air, fast black coating, adjustable rebound, tapered alloy steerer, 110mm x 15mm boost, maxle lite | crankset | whyte, forged 2pcs cranks, direct mount 32t narrow/wide chainring, 170mm, 11 speed |
| rear shock | n/a | bottom bracket | bsa, cartridge bearings, 73mm |
| headset | fsa no. 57b orbit zs, 1 1/2" lower and 1 1/8" upper caged bearings | seatpost | whyte drop.It, 30.9mm, xs/s 125mm, m 150mm travel, alloy remote lever |
| rear hub | alloy, double sealed cartridge bearings, 10mm x 148mm boost thru axle, 32 hole | saddle | whyte custom |
| front hub | alloy, double sealed cartridge bearings, 15mm x 110mm boost thru axle, 32 hole | handlebar | whyte 6061 alloy, 15mm rise, 31.8mm, xs 740mm wide, s/m 760mm wide |
| spokes | dt swiss champion 2.0mm, black stainless, brass nipples | stem | whyte alloy, 40mm extension |
| rims | wtb st i27 tcs 2.0 system, pinned joint, tubeless ready, 32 hole | grips | whyte lock-on enduro grip |
| tyre | maxxis high roller ii tr 27.5"x 2.4" 60tpi, exo sidewall protection, 3c maxx terra, front, maxxis forekaster tr 27.5" x 2.35" 60tpi, exo sidewall protection, dual compound, rear | brakes front | tektro hd-m535 , 4 piston, 180mm, 2.3mm gauge, 180mm disc |
| shift levers | shimano deore sl-m5100, 10 speed | brakes rear | tektro hd-m535 , 4 piston, 180mm, 2.3mm gauge, 180mm disc, internal routing |
| front mech | n/a | brake levers | tektro hd-m535 |
| rear mech | shimano deore rd-m5100-sgs, shadow plus, 11 speed | pedals | fibre reinforced composite platform |
| weight | 12.9 kg | | |
